HORIZONTAL SCROLLVIEW

If you are not familiar with creating a simple app GoTo our Tutorial How to create a simple App in Android for tablets. Just name it "Japanese", if you are following along with this tutorial.

What the App 'Japanese' Will Look Like

Once you add the code and images, your app should look similar to this one.

Because the images we added exceed the width of the physical screen; the 'horizontal scroll' allows the images to be scrolled to the right of the display's physical parameter; and then you can scroll left also.
Android Tutorial, Horizontal Scroll View

Android Tutorial, Horizontal Scroll View

For this tutorial: The Code For the Horizontal Scroll View

To add a horizontal scroll view to your android app you need to add the horizontal scroll view code as shown in this image.

FOR THIS TUTORIAL

The Code For the Images

For an android horizontal scroll view, you add images to the layout file code in the same manner as if you were just adding an image.

Use:

android:layout_width:="wrap_content", and android:layout_height:="wrap_content", and add:

android:src="@drawable/verbtothink".

All images are placed in the res/drawable-hdpi folder, you don't need to code the .png, because it is in the drawable folder the android system knows it is an image. Although we are using the same image several times in this scrollview app, we need only add it one time to the res/drawable-hdpi folder.

The Code For the App Icon

Coding for the App icon is placed in the manifest file as shown in this image.
The App icon image is placed in the drawable-hdpi folder; and coded in the manifest file as: android:icon="@drawable/yomu"

coding the app icon in the manifest file

A label(text) can be added with the App Icon and it is placed next to the App Icon at top of screen display.
To code the label we use the android:label="@string/app_name", which is coded in the manifest file, in the application code. The actual text you use is placed in the strings.xml file, which is at res/values/strings.xml, and is coded as shown in this image. For this app our label text reads: Japanese Verbs.
coding strings in android

Coding Tips - FYI

Horizontal Scroll View

By default the images are placed next to each other. If you want space between each image you can do so by using this code:

android:layout_marginLeft="5dp"

You can change this as you like for the spacing. For our tutorial app: Japanese, we added this code to some of the images.

Additional reading at Android Developer Website on 'horizontal scroll view'

....horizontal scroll view attributes

EXAMPLE CODE; Code For This Tutorial

This is the code for this app 'Japanese ' THE - Horizontal Scroll View tablet tutorial; so you can just copy and paste it into your layout file: main.xml

Also, code your manifest file to include the app icon name as shown in the image on this page,'android:icon="drawable/yomu' and code your strings.xml file to say 'Japanese Verbs';'string name='app_name Japanese Verbs, and finally,

SAVE, the two images shown in the Example Code to your tablet, then copy and paste them into your AppProjects/Japanese App at res/drawable-hdpi folder. Use your tablet`s file manager to paste the files into the apps drawable folder. You cannot paste them directly from within the AIDE editor.

TO COMPILE AND RUN YOUR APP:
App Name is 'Japanese' - located at AppProjects/Japanese in AIDE, open the AIDE app, then open App Projects, THEN select the 'Japanese', app from your files hierachy; then click on a file from the app, like strings.xml Make sure at top of page, the app name Japanese is there next to AppProjects like so: AppProjects/Japanese, then you know you have the proper App. Once a file is in the editor, you can save it, then RUN your APP.

Make sure you SAVED EACH PAGE, before you RUN your code. SAVE, RUN, INSTALL, OPEN, your Japanese App. Once it has been installed on your tablet, you can open it Simply by Clicking on the App Icon, YOMU, from the apps directory on your tablet. Just look for the YOMU icon, as shown in this tutorial.
If you make further changes to this Japanese App, you need to SAVE, RUN, UPDATE, OPEN the app.

Example Code:
Use Mouse To Copy Paste the Code

COPY THIS CODE FROM HERE AND place at main.xml file, then save file

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
	android:layout_width="fill_parent"
	android:layout_height="fill_parent"
	android:orientation="vertical">

	<HorizontalScrollView
		android:layout_width="wrap_content"
		android:layout_height="wrap_content">

	<LinearLayout
 android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:layout_marginTop="165dp"
android:orientation="horizontal" >

<ImageView
			android:layout_width="wrap_content"
			android:layout_height="wrap_content"
			android:src="@drawable/verbtothink"/>


		<ImageView

			android:layout_width="wrap_content"
			android:layout_height="wrap_content"
			android:src="@drawable/verbtothink"/>

		<ImageView

			android:layout_width="wrap_content"
			android:layout_height="wrap_content"
			android:src="@drawable/verbtothink"/>

	<ImageView

		android:layout_width="wrap_content"
		android:layout_height="wrap_content"
		android:src="@drawable/verbtothink"/>

	<ImageView

		android:layout_width="wrap_content"
		android:layout_height="wrap_content"
		android:src="@drawable/verbtothink"/>


	<ImageView

android:layout_width="wrap_content"
		android:layout_height="wrap_content"
		android:src="@drawable/verbtothink"/>

	<ImageView

		android:layout_width="wrap_content"
		android:layout_height="wrap_content"
		android:src="@drawable/verbtothink"/>

	<ImageView

		android:layout_width="wrap_content"
		android:layout_height="wrap_content"
		android:src="@drawable/verbtothink"/>

	<ImageView

		android:layout_width="wrap_content"
		android:layout_height="wrap_content"
		android:src="@drawable/verbtothink"/>





			<ImageView
				android:layout_width="wrap_content"
				android:layout_height="wrap_content"
				android:layout_marginLeft="5dp"

				android:src="@drawable/verbtothink"/>


		<ImageView
			android:layout_width="wrap_content"
			android:layout_height="wrap_content"

			android:layout_marginLeft="5dp"
			android:src="@drawable/verbtothink"/>

		<ImageView
			android:layout_width="wrap_content"
			android:layout_height="wrap_content"
			android:layout_marginLeft="5dp"
			android:src="@drawable/verbtothink"/>

		<ImageView
			android:layout_width="wrap_content"
			android:layout_height="wrap_content"
			android:layout_marginLeft="5dp"
			android:src="@drawable/verbtothink"/>


	</LinearLayout>
</HorizontalScrollView>

</LinearLayout>

Save these images to your tablet, then place in res/drawable-hdpi folder of the AppProject 'Japanese'
yomu.png is your 'app icon' image; save it to the res/drawable-hdpi folder, and code it in the manifest file
verbtothink.png is the image for the horizontal scroll; save it into the res/drawable-hdpi folder It is coded in the layout file.
